Magcat

Meet Magcat – our most powerful and versatile dual treatment conditioner

The Magcat launched in 2008 following years of research and development. The Magcat is a two stage commercial and industrial water conditioning system suitable for treating potable, processed, recycled or waste water and providing the most complete reaction available for calcium carbonate treatment.

DOWNLOAD DATASHEET

OUR DUAL TREATMENT SYSTEM

Combining magnetic and catalytic technology, we created our most innovative, versatile and powerful conditioning products to date.
Our dual treatment conditioner is the only self-powered, compact product on the market specifically designed for a wide range of flow rates and water chemistry.

RESIDENTIAL & COMMERCIAL

Benefits of using Magcat

Truly sustainable – 100% recyclable at end of life

10 year pro-rata warranty

Water can stay effectively treated for up to 3 months

Prolongs the life of water using applications and heating systems

Reduces limescale build-up in pipes, valves, pumps and heating elements

Reduces energy consumption generating cost savings

World class dual treatment technology – capable of treating wide flow rate range

Easy to install – horizontally or vertically, with low weight and small footprint

Cost effective, proven and sustainable

No metals leaching into the water

No upper limit to water hardness that can be treated

No upstream or downstream space required

Self powering – no power needed, no BMS required and zero energy use

Green technology

No power
No electrical connections
No chemicals
No consumables
No waste water

Peace of mind

No maintenance
No servicing
No earthing or bonding required
No control box to mount
Up to 20 years service

Magcat applications

Whole house protection

Apartment blocks

Commercial offices

Schools

Universities & colleges

Leisure centres

Maritime transport

Cinemas

Retail parks / shopping centres

Restaurants

Farming / irrigation

Marine applications

Magcat materials of construction

Stainless steel housing – WRAS approved

Non-sacrificial catalytic semi precious alloy (lead free) – WRAS approved

Magnets – stainless steel coated magnets – WRAS approved

Magcat life expectancy

Dependant on use, a minimum of 10 years service can be expected, however it is not uncommon for our conditioners to last between 15-25 years +

Magcat regulatory

WRAS Approval No: 1812306

Reg4 Approval No: 2312017

Magcat pressure losses

Magcat data table

Magcat installation guide

Sizing

Size matters – selecting the right conditioner is critical

Selecting the wrong size conditioner – including using a larger diameter than needed – can compromise water delivery and affect treatment quality

Conditioner size should be selected based on flow rate

In general applications where the flow rate is known to be low or there is relatively heavy scale build-up inside the pipe already. In this instance, a conditioner 1 size smaller than the pipe diameter is recommended.

Fitting options

Fluid Dynamics has a wide range of connection options available – please ask.

COMMON THREADS

UK: BSPT CONNECTIONS (DN15 TO DN50)

½” to 2” BSPT (British Standard Pipe Tapered) threads
These conform to BSP (British Standard Tapered)

FLANGES – DN65 UPWARDS (2.5” +)

A wide range of flanges can be specified as the fitting option required

UK

Standard fitting in the UK is the BS4504 PN16 stainless steel flanges
Higher pressure ratings are available upon request
Maximum operating temperature = 120 degree Celsius

Installation: Our conditioners can be installed both vertically and/or horizontally

Environmental data
