Scaletron
Introducing Scaletron, specifically engineered to cater to the requirements of the commercial and industrial sectors
Launched in 1982, the Scaletron is one of our flagship models designed exclusively for the commercial and industrial sectors. It’s designed to reduce and prevent limescale build-up across a variety of commercial and industrial applications and settings – improving efficiency and extending the lifespan of heating equipment. Scaletron’s versatility and effectiveness make it a favourite for our commercial customers, and having won an industry award, it provides complete peace of mind.
COMMERCIAL & INDUSTRIAL
Benefits of using Scaletron
Prolongs the life of water using applications and heating systems
10 year pro-rata warranty
Environmentally friendly – reduces energy consumption, carbon emissions & footprints
Reduces limescale build-up in pipes, valves, pumps and heating elements
Lower energy consumption = lower energy bills
Stainless steel – corrosion resistant
Easy to install – horizontally or vertically
Cost effective, proven and sustainable
Green technology
No power
No electrical connections
No chemicals
No consumables
No waste water
Peace of mind
No maintenance
No servicing
No earthing or bonding required
No control box to mount
Scaletron applications
Apartment blocks
Commercial offices
Schools
Universities & colleges
Leisure centres
Maritime transport
Cinemas
Retail parks / shopping centres
Restaurants
Farming / irrigation
Marine applications
Scaletron materials of construction
Stainless steel housing
Non-sacrificial catalytic semi precious alloy (lead free) – WRAS approved
Brass compression coupling fittings EN1254-2 or BSP Male Threads
Blue plastic sleeve – approved to UL 224 VW-1 & ROHS Compliant
Scaletron life expectancy
Dependant on use, a minimum of 10 years service can be expected, however it is not uncommon for our conditioners to last between 15-25 years +
Scaletron regulatory
WRAS Approval No: 2209048
Scaletron installation guide
Sizing
Size matters – selecting the right conditioner is critical
Selecting the wrong size conditioner – including using a larger diameter than needed – can compromise water delivery and affect treatment quality
Conditioner size should be selected based on flow rate
In general applications where the flow rate is known to be low or there is relatively heavy scale build-up inside the pipe already. In this instance, a conditioner 1 size smaller than the pipe diameter is recommended.
Fitting options
Fluid Dynamics has a wide range of connection options available – please ask.
COMMON THREADS
UK: BSPT CONNECTIONS (DN15 TO DN50)
½” to 2” BSPT (British Standard Pipe Tapered) threads
These conform to BSP (British Standard Tapered)
USA: NPT CONNECTIONS (DN15 TO DN50)
½” to 2” NPT (National Pipe Taper) Male & Female Threads
These conform to ANSI / ASME Standard B1.20.1
FLANGES – DN65 UPWARDS (2.5” +)
A wide range of flanges can be specified as the fitting option required
UK
Standard fitting in the UK is the BS4504 PN16 stainless steel flanges
Higher pressure ratings are available upon request
Maximum operating temperature = 120 degree Celsius
USA
The standard flange fitting in the USA is ASA 150 stainless steel flanges
Higher pressure ratings are available upon request
Maximum operating temperature = 120 degree Celsius
Installation: Our conditioners can be installed both vertically and/or horizontally
