Introducing iMagCat – our two-stage industrial water conditioning system

A reflection of our ongoing commitment to innovation, the iMagCat launched in 2008 following years of research and development. The iMagCat is a two-stage industrial water conditioning system suitable for treating potable, processed, recycled or waste water. It combines Fluid Dynamics’ magnetic and catalytic treatment systems into a single housing, providing the most complete reaction available for calcium carbonate treatment.

DOWNLOAD DATASHEET

OUR DUAL TREATMENT SYSTEM

Catalytic treatment is suitable for around 90% of the world’s potable water, however it is not suitable for water where the alloy can become fouled with iron or where water is already supersaturated with high levels of minerals. This led us to the development of dual technology – combining magnetic and catalytic technology to create our most innovative, versatile and powerful conditioning products to date.

FLUID DYNAMICS INDUSTRIAL

Benefits of using iMagCat

Minimum service of 15 years

10 year pro-rata warranty

Prolongs the life of water using applications and heating systems

Water stays treated for over 3 months

Reduces limescale build-up in pipes, valves, pumps and heating elements

Reduces energy consumption generating cost savings

Reduces carbon emissions – green technology for the future

Easy to install – horizontally or vertically

Strong and corrosion resistant: stainless steel

Cost effective, proven and sustainable

No metals leaching into the water

Green technology

No power
No electrical connections
No chemicals
No consumables
No waste water

Peace of mind

No maintenance
No servicing
No earthing or bonding required
No control box to mount

iMagCat applications

Marine applications

Apartment blocks

Commercial offices

Schools

Universities & colleges

Leisure centres

Maritime transport

Cinemas

Retail parks / shopping centres

Restaurants

Farming / irrigation

iMagCat materials of construction

Stainless steel housing

Non-sacrificial catalytic semi precious alloy (lead free) – WRAS approved

Magnets – Xylan coated alloy magnets – WRAS approved

iMagCat life expectancy

Dependant on use, a minimum of 10 years service can be expected, however it is not uncommon for our conditioners to last between 15-25 years +

iMagCat regulatory

WRAS Approval No: 1812306

iMagCat pressure losses

iMagCat data table

iMagCat installation guide

Sizing

Size matters – selecting the right conditioner is critical

Selecting the wrong size conditioner – including using a larger diameter than needed – can compromise water delivery and affect treatment quality

Conditioner size should be selected based on flow rate

In general applications where the flow rate is known to be low or there is relatively heavy scale build-up inside the pipe already. In this instance, a conditioner 1 size smaller than the pipe diameter is recommended.

Fitting options

Fluid Dynamics has a wide range of connection options available – please ask.

COMMON THREADS

UK: BSPT CONNECTIONS (DN15 TO DN50)

½” to 2” BSPT (British Standard Pipe Tapered) threads
These conform to BSP (British Standard Tapered)

USA: NPT CONNECTIONS (DN15 TO DN50)

½” to 2” NPT (National Pipe Taper) Male & Female Threads
These conform to ANSI / ASME Standard B1.20.1

FLANGES – DN65 UPWARDS (2.5” +)

A wide range of flanges can be specified as the fitting option required

UK

Standard fitting in the UK is the BS4504 PN16 stainless steel flanges
Higher pressure ratings are available upon request
Maximum operating temperature = 120 degree Celsius

USA

The standard flange fitting in the USA is ASA 150 stainless steel flanges
Higher pressure ratings are available upon request
Maximum operating temperature = 120 degree Celsius

Installation: Our conditioners can be installed both vertically and/or horizontally
